Perilla Seed Oil Pressing Line

Perilla seed oil is sensitive to unnecessary heat, air exposure, and long holding times. Cold-pressed and roasted perilla oils must be treated as separate product routes with separate trial records.

Raw Material Boundary

Declare seed variety, origin, moisture, impurities, storage time, damaged or moldy fraction, and intended use. Quote capacity on cleaned seed. Old, rancid, or mixed herb residue is not equivalent to sound oilseed feed.

Recommended Pretreatment

1. Screen and clean the small seed.
2. Remove stones, metal, dust, and damaged seed.
3. Dry gently when moisture requires correction.
4. Break the seed structure consistently without prolonged open-air storage.
5. Keep cold-press and roasted trial lots separate.

Pressing Route and Equipment

Use a low-temperature hydraulic batch trial as the primary route when a light flavor and controlled oxidation are required. Roast or warm-condition a separate sample only when the intended product calls for a stronger aroma. For larger continuous duty, compare a screw press using the same finished-oil criteria.

Equipment Entry Points

• Pretreatment equipment
• Hydraulic oil press range
• 426 Series hydraulic oil press as an existing model entry for trial sizing
• Pneumatic filter press
• Filling equipment

Filtration and Finished-Oil Target

Set the settling or filtration period, visible sediment, clarity, color, aroma, oxidation test method, and time to closed storage. Specify tanks and light-protective packages that match the agreed finished-oil handling plan.

Data Required for a Quotation

• Seed sample, variety, moisture, impurities, damaged fraction, storage time, and signs of oxidation
• Dry-seed input per batch or day, operating hours, and required duty cycle
• Cold-pressed or roasted aroma target and oil-temperature monitoring needs
• Settling, filtration, tank, package, sampling, and oxidation-test requirements
• Power, heat if used, floor space, storage conditions, destination, and delivery terms

Acceptance Records

Record seed moisture, cleaning loss, crush condition, roast or conditioning settings where used, charge weight, cycle time, oil temperature, crude and filtered oil, cake, and elapsed open-air time. Check clarity, color, aroma, rancid notes, tank closure, package suitability, retained product, and cleaning under the agreed sample conditions.
